IP65 600W LED Pixel Panel

HTK-LS600P-IP

HTK-LS600P-IP is designed as a compact yet powerful LED pixel strobe light with 800 pcs 0.5 watt RGB tricolor LEDs, and 200 pcs 3 watt 6500K white LEDs. It can be used as a wall washer and a powerful strobe.
shared：

Input Voltage:AC100-240V 50/60Hz

Power: 600W

Strobe power: 1000W

LED(Panel):800x0.5W RGB tricolor SMD5050 LEDs

LED(Tube):200X3W SMD3535 6500K LEDs

Pixel segment: 40 pixel in panel, 30 pixels in tube

Lifespan:min 50000 hours

Control Mode: DMX, Auto-run, Master/slave, Sound

DMX Channel: 15CH/50CH/158CH

Strobe: 0-20Hz, variable flash rate, intensity and duration

Dimmer modes: 5 dimmer modes

Dimmer curve: 4 dimmer curves

Effect: various inbuilt macro color effect

IP Rating: IP65,waterproof

Invironment Temp: -30°C - 50°C

Singnal Connector: IP65 3 pin DMX in&out

Power Connector: IP65 power in&out

Housing: die-cast alluminun

Cooling: entire housing as heat sink+IP65 fan

Display:touch screen LCD display

Size: 41X21X16cm

N.W.: 9.5 KG
